Catchment management

Catchment Trial Farm

Background
Due to elevated pesticide levels measured in the raw water of Blithfield Reservoir, South Staffs Water has a programme of catchment management within the Blithfield catchment, aimed at improving water quality at source. The Blithfield catchment is dominated by the River Blithe which feeds into Blithfield reservoir, a significant  source of the company’s water supply. The catchment management programme includes support for on farm measures and product substitution through the SPRING scheme, along with advice on best practice and other measures.

Atkin Farms

Atkins Farm sign

Atkin Farms is located within the Blithfield Catchment area. The catchment area is approximately 65-70% pasture and mixed farming and 30-35% arable. Atkin Farms is a 930 acre mixed farm, 80% arable and 20% grassland. It is situated north of the reservoir and has the river Blithe running through the farm alongside several of its fields. Rob Atkin is an innovative farmer, keen to trial new methods and machinery to help reduce pollution of the watercourses and has been working in partnership with South Staffs Water for two years, as a trial farm for showcasing and testing farming techniques that benefit water quality risk in the catchment.

Mzuri Drill

Mzuri drill2018 was an exciting trial year due to the purchase of a Mzuri strip till drill, a one-pass drill that cultivates, drills, and reconsolidates the ground in one go. This conservation farming method improves soil moisture and organic matter content whilst reducing soil erosion and run off which negatively impact upon water quality.

The Mzuri drill was used to drill a field of spring barley, in an adjacent field to spring barley that was drilled with Atkin Farms’ regular min-till methods.

The differences in drilling methods did not have an effect on the establishment or growth of the crops, with the crops in both fields growing well throughout the short season. The trial achieved a negligible loss in yield (0.05t/acre) with the Mzuri method compared to the farm’s standard min-till method. Changes to no till practices can often take years to see improvements, often undergoing yield losses in the first years of adjustments (UEA, 2017), so to achieve a negligible loss in yield in the first year of use, in drought conditions is very encouraging.

With the Mzuri strip till method being a single pass method, the input costs are reduced by £10 per acre compared to the farm’s usual min till method (Table 1). The single pass technique is balanced out by the fact that the process is slower. The drill is slower that the Farmer, Rob’s current drill and has half the boom width, so it is certainly beneficial that only one pass is needed.

Table 1. Differences in drilling cost and spring barley yield with the different cultivation techniques on Atkin Farms.

Method Drilling costs Yield
Mzuri £28/ac 1.90 t/ac
Min Till £38/ac 1.95 t/ac
Conventional drilling* £44/ac (average) n/a

* method not used on Atkin Farms, drilling cost information taken from farmers weekly and added for comparison

The initial experience of the drill has been positive. We would not have expected to see remarkable increases in yield at this stage. As Rob put it:

“It’s a process, it’s too soon to see an organic matter build up and soil structure improvement, but for now it’s enough to know that this is being improved over time”. The slow improvement process is the biggest challenge encouraging the uptake of these no till methods by farmers, the fact that Rob sees the process is very helpful, it means we can continue to use and showcase the drill on his farm to local farmers.

Cover crops

Cover cropsAn initial trial into overwinter cover cropping before maize planting has provided anecdotal evidence of reductions of soil erosion and run off. The cover crops endured the ‘beast from the east’ and the cover cropped field was noticeably drier than the surrounding bare fields, so much so that the maize was able to be sown earlier in this field than the others.

A catchment friendly grazing pattern of stubble turnips was also trialled. On a sloping field, the sheep usually graze bottom to top to work up to drier ground over winter. This year that system was reversed, leaving vegetation at the bottom of the slope to soak up water and trap sediment. This had noticeable benefits to the soil erosion usually observed. No gullies had been created down the slope and the soil was not poached-up by the sheep, as it often is. The tenant farmer commented that the field often floods in one corner and this was not observed this winter.

Cover crops will continue to be trialled over winter 2018 before Spring 2019 planting.

For more information about the trials, or the SPRING scheme please contact catchment.management@south-staffs-water.co.uk.
